Our proprietary anode material is built for batteries that must survive storage, abuse, and field conditions, not just lab benchmarks.
Talk to a Battery SpecialistObsidia™
A Smarter Integration Path
Most advanced anode materials promise more energy, but deliver new problems: swelling, qualification complexity, and manufacturing overhaul. Obsidia takes a different approach, while still providing an energy-density boost. It's designed to make graphite-based lithium-ion batteries tougher, without asking manufacturers to start over.
Obsidia works with graphite, not instead of it. As a graphite-blend additive, it can be evaluated in existing cell designs, lowering qualification risk while improving performance where it matters most.
10%
Obsidia
+
90%
graphite
C-BATT's near-term
commercial blend
commercial blend
~390
mAh/g
Projected anode capacity vs. graphite's
theoretical ceiling of ~372 mAh/g
theoretical ceiling of ~372 mAh/g
Compatible with existing lithium-ion cell
designs and manufacturing processes
designs and manufacturing processes
Built Different. Built to Last.
Low Swelling
Conventional silicon anodes can expand by hundreds of percent during cycling, degrading electrodes and shortening cell life. Obsidia’s coal-derived, silicon-containing carbon architecture is engineered to absorb lithium with minimal volume change.
Stat: ~2–5% reversible volume change in university testing vs. hundreds of percent for typical silicon-rich anodes
Deep-Discharge Tolerance
Obsidia-containing cells have been tested under extreme conditions, including discharge toward ~1.0V, where conventional graphite cells often fail permanently.
Stat: Cells cycled to 1.0V hundreds of times show no capacity degradation and no copper dissolution in their electrolyte
Long-Storage Resilience
For batteries that sit in the field, on a shelf, or in a machine for months before use, Obsidia blends are designed to deliver. When the mission calls, the battery answers.
Stat: 2+ years of fully discharged storage tested without measurable capacity loss
Performance at a Glance
| Conventional Graphite | Silicon-Rich Anodes | Obsidia™ Blend | |
|---|---|---|---|
|
Anode Capacity
|
~372 mAh/g (theoretical)
|
Higher, varies
|
~390 mAh/g
|
|
Volume Expansion
|
~10%
|
Up to hundreds of %
|
~2–5% (university testing)
|
|
Deep-Discharge Tolerance
|
Low
|
Varies
|
Designed-in
|
|
Long Storage Resilience
|
Limited
|
Varies
|
2+ years tested
|
|
Drop-in Integration
|
|
Often no
|
|
|
U.S.-Made
|
Rarely
|
Varies
|
|
Anode Capacity
Conventional Graphite
~372 mAh/g (theoretical)
Silicon-Rich Anodes
Higher, varies
Obsidia™ Blend
~390 mAh/g
Volume Expansion
Conventional Graphite
~10%
Silicon-Rich Anodes
Up to hundreds of %
Obsidia™ Blend
~2–5% (university testing)
Deep-Discharge Tolerance
Conventional Graphite
Low
Silicon-Rich Anodes
Varies
Obsidia™ Blend
Designed-in
Long Storage Resilience
Conventional Graphite
Limited
Silicon-Rich Anodes
Varies
Obsidia™ Blend
2+ years tested
Drop-in Integration
Conventional Graphite
Silicon-Rich Anodes
Often no
Obsidia™ Blend
U.S.-Made
Conventional Graphite
Rarely
Silicon-Rich Anodes
Varies
Obsidia™ Blend
Pre-production and university testing. Larger-format validation underway. Results may vary.
American Material.
Secure Supply.
The battery anode supply chain is heavily dependent on foreign graphite processing. Obsidia is developed from verified U.S.-sourced material inputs through a domestic manufacturing pathway, making it not just a performance material but a supply-chain asset for defense and critical infrastructure customers.
What Obsidia Does
Obsidia is designed to help graphite-based lithium-ion batteries perform better in real-world conditions.
Low swelling under cycling
Deep-discharge tolerance
Long-storage resilience
Durable cycling performance
Practical graphite-blend integration
Verified U.S. material sourcing
Advanced Anode Performance. Practical Integration.
Obsidia™ is designed for battery manufacturers and engineers who need greater durability, deep-discharge tolerance, and long-term storage resilience.
Our blend-first approach means lower qualification risk, familiar manufacturing processes, and a more secure domestic supply chain.
+.-
